Flexible wires are copper wires with variety of domestic and commercial uses. A common application of copper multicore flexible wires is in Airconditioing systems - both for power as well as signalling. Another common use of flexible wires is in industries for power supply as well as control signalling. Now these muticore flexible wires are available to buy online.

Product specification
BrandRR Kabel
Product Category2, 3, 4 & 6 Core Cables
Size of Conductor1.5 sq mm
Core3 Core
Length100 mtr
Conductor MaterialCopper
ColourBlack
Insulation MaterialPVC
Current Rating AC18 Amp
Resistance (Max.) per Km at 20° C13.3 ohm
Thickness of Insulation (Nom.)0.6 mm
Nominal Thickness of Sheath0.9 mm
Max. Overall Diameter9.3 mm
Voltage Drop (DC or Single Phase AC)31 mV
Voltage Drop (3 Phase AC)26 mV
CertificationIS-694:2010
Manufacturer DetailsRam Ratna House, Utopia City, P. B. Marg, Worli, Mumbai, Maharashtra - 400013, India
